    Gloss Finish Roll Wrapped 15MM Carbon Fiber Tube Twill Weave UV Resistant

    Ask Lasest Price
    Brand Name : Tanku
    Model Number : OEM
    Certification : SGS, ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 1500pcs month
    Delivery Time : 7 working days after receiving Order Pay
    • Product Details
    • Company Profile

    Gloss Finish Roll Wrapped 15MM Carbon Fiber Tube Twill Weave UV Resistant

    UV Resistant Twill Weave Gloss Finish Roll Wrapped 15MM Carbon Fiber Tube

    Roll Wrapped Carbon Fiber Tube Silver Aluminized Twill Weave Gloss Finish – This carbon fiber tube uses a high-strength unidirectional equivalent carbon fiber core with an epoxy resin system to ensure a strong rigid tube that will meet your needs. In addition to this high-strength unicore, this tube is finished with a beautiful 2×2 twill weave Silver Aluminized Fiberglass and then given a gloss finish. Due to raw material constraints, it is hard to create pipes exactly at a specific measurement unless they are built over-sized and machined down so that is why our pipes may be a few thousandths off from the ideal measurement we are trying to match.


    We offer many composite tubing varieties if this tube does not meet your needs. We offer pultruded materials in a round solid bar, pipe, and square bar/tubing. Upon special order, all of our unique fabrics can be converted into piping.


    What is pullwinding process?


    Pullwinding is an advanced pultrusion process to produce round tubes and profile tubes. Pullwinding technology gives the possibility to have accurate control of the crosswise and longitudinal properties of the final product by adjusting the amount of fibers lengthwise and crosswise. Pullwinding process enables the reduction of wall thickness and weight while retaining and improve stiffness and strength compared to conventional pultrusion.


    The benefits of carbon fiber tubes

    • High strength and stiffness with low weight
    • Excellent fatigue resistance
    • Dimensional stability: Low to Zero CTE (Coefficient of Thermal Expansion)
    • Extreme low weight
    • Easy to use in a big variety of applications
    • Carbon fiber tubes applications
    • Carbon fiber can be used in a great number of applications, from industrial markets such as automotive, infrastructural engineering and construction, to motorsports, the built of yachts and other industries.

    Furthermore, Carbon fiber tubes can also be implemented in the construction of lightweight bikes, roofing, sun protectors and so on.


    Roll Wrapping:


    The phrase ‘roll wrapped’ refers to the process used to manufacture these tubes. The prepreg carbon fibre is first laid up around a mandrel in multiple layers. Once the reinforcement is in place it is spiral-wrapped with heat-shrink tape before the whole assembly is oven cured.


    Common Applications of Carbon Fiber tube

    • Aerospace beam and spars
    • Telescopes
    • Arrows
    • Robotics
    • Arrow Shafts
    • Bicycle frames
    • Kayak paddles
    • RC models
    • Yachts
    Material15MM Carbon Fiber Tube
    ShapeRound/Oval
    TechnologyRoll-wrapped or pultrusion
    DimensionThe existing inner diameter of the mold is 4mm-50mm with a length of 1m.
    Customizable size: The maximum diameter can be 200mm, the longest can be 3m.
    SurfaceBlack glossy/matte surface/painted
    Glossy 3k weave/matte 3k weave
    Color metal wire weave
    Featurelightweight, high strength
    Working TemperatureUsually, -30-120 degrees, if special requirement, please let us know.
    Place Of OriginChina
    FunctionMarine, Agriculture Tools, Arrow Shaft, Medical, Sport Products
    ToleranceDiameter Tolerance: +/-0.1mm
    Length Tolerance+/-1mm


    Our Service:

    1. It ensures that a year of quality assurance and 24 hours online customer service.
    2. Protection of your sales area, ideas of design, and all your private information.
    3. Request for samples is accepted.
    4. Drilling and slotting are accepted.
    5. We guarantee the products to be manufactured with the finest materials and mature technics.
    All tubes can be repaired at no charge if returned to us, postage prepaid, within one year.
