Round Filament Wound Carbon Fiber Tube For Marine , Automotive Industry

Filament Wound Carbon Fiber Tube Introduction

Carbon fiber composite tube has great advantage in high strength & light weight, the strength of carbon fiber reinforced polymer is 6-12 times of steel, and density is less than 1/4 of steel. Based on their superior mechanical properties, they can be used to replace or substitute aluminum or steel tubes in a wide range of projects. Widely used in telescopic pole, exhaust Pipe, paddle etc.

Filament Wound Carbon Fiber Tube Specification

Carbon fiber winding of molding process

Winding molding process is soaked in resin adhesive solution of continuous fiber (or cloth belt, presoak

yarn) on winding to the mandrel according to certain rules, and then after curing, demoulding, obtain

products.According to the filament winding forming physical and chemical condition when the resin is

different, divided into dry winding, wet winding and half dry winding 3 kinds.(1) dry winding Dry winding is

adopted through presoak rubber processing presoak yarn or, on a winding machine after soften to

viscous flow winding onto the mandrel.Because of presoak yarn (or with) is a professional production, to

strictly control the resin content (accurate to 2%) and presoak yarn quality.Therefore, dry winding can

accurately control the quality of the product.Dry winding process is the biggest characteristic of high

production efficiency, winding speed can reach 100 ~ 100 m/min, winding machine cleaning, labor health

condition is good, high product quality.The downside is winding equipment is expensive, need to increase

in yarn manufacturing equipment, so the investment is bigger also, dry low interlaminar shear strength

of winding products.

Filament Wound Carbon Fiber Tube ​Packaging

Shanghai Lijin focuses on the Carbon Fiber industry and offers carbon fiber tubes, plates, and aluminum CNC services.

Being experienced in the carbon fiber applications for over 7 years, Shanghai Lijin manages customized production according to various industry standards. Shanghai Lijin started to keep in stock for some standard

sized and frequently ordered tubes and plates. This enables Shanghai Lijin to make prompt delivery. Not only

can Shanghai Lijin complete mass production orders in short period, we can even ship normal sample, prototype orders of Carbon Fiber Plate CNC parts in just SEVEN days after order confirmation when the

drawings are available. Shanghai Lijin is dedicated to solve any technical points during the production and new item developing to ensure the quality.

Carbon Fiber tube production is Shanghai Lijin’s core business and occupies 70% of our turnover.
The carbon fiber tubes Shanghai Lijin mainly produce is table-rolled and oven thermoset. The tubes can be Full Carbon or Carbon Fiber and Fiberglass composite, depending on the application, weight limit,mechanical

strength and surface requirement.Shanghai Lijin offers top quality ROUND carbon fiber tubes. The general OD tolerance we achieve is +/-0.10mm and it can be even +/-0.05mm after our special surface process.

The maximum length of the tube can be 5500mm.

Besides the traditional table-rolled carbon fiber tubes, Shanghai Lijin also offers REAL Filament wound carbon fiber tubes,which are widely used for mechanical strength like auto driving shaft, antennas, even for military

applications. The filament wound carbon tubes are wound at a certain angle like 30 or 45 degree. We invested the new production line from Jun 2013 and this increases Shanghai Lijin’s advantage in the carbon

fiber tube industry. There are just a few real filament wound carbon fiber tube manufacturers in domestic

China and we are one of them.
